Allen Bradley 1785 L46B

The Allen Bradley 1785 L46B, as the main CPU of the PLC 5 series, can control the entire 1771 I/O rack. It has ample memory to handle the logic of medium and large-scale production processes and has been widely used in industrial sites that have been in operation for many years. Feimu Technology, as the original supplier, checks the incoming modules layer by layer, conducts a full set of tests such as power-on communication, simulated load and long time copying, eliminates the hidden dangers of aging and maintenance and renovation of components in advance, and can be directly put into production when hands are obtained.

Technical specifications

The core advantage and selling point

Large capacity program storage + PLC-5 mature architecture + compatible with existing industrial systems + suitable for replacement and maintenance

48 k Words user memory

Support the DH + / Remote I/O

Apply to PLC - 5/1771 system

Suitable for replacement of spare parts for discontinued PLC-5 systems

Can be used in the old automation equipment maintenance and system prolong life

Reduce the renovation cost caused by upgrading the entire control system

Installation Process

Confirm the model and system:

Confirm the Allen Bradley 1785 L46B with existing PLC - 5 frame, 1771 I/O module and communication system matching.

Disconnect the system power supply:

Turn off the power supply of PLC frame before installation to avoid damage caused by live plug and remove.

Check the processor:

Check appearance, interface, pin and nameplate to confirm no obvious damage.

Install processor:

Aim the processor PLC - 5 frame corresponding slot, ensure mesh and backplane connector completely, and the fixed module.

Connection communication lines:

Connect the DH+ or Remote I/O communication lines according to the system configuration, and check the connection firmness.

Put through power supply:

Restore the PLC system power supply and observe the processor status indicator to confirm that there is no abnormal fault indication.

The software configuration and test:

RSLogix 5 is used to establish communication with the processor, check the processor status, program running status and I/O communication.

System run validation:

Test the digital I/O, remote I/O and communication functions one by one, and confirm the normal operation of the control system and put it into production.

Field of Application

Automobile production line

Equipment for packing

Water treatment system

Material handling system

Petroleum chemical equipment

Iron and steel and metallurgical equipment

Old PLC-5 control system maintenance

Case: some overseas manufacturing enterprise PLC - 5 system maintenance

The customer's original control system adopts PLC-5 architecture. Due to the failure of the original processor, we need to find replacement parts of the same model. We according to the customer to provide 1785 - L46B nameplate information confirm type and version, and appearance inspection, electricity and communications testing after shipment, used for the original system maintenance.

Service life

The Allen Bradley 1785 L46B belongs to the older model of PLC-5 industrial controller. Its actual service life is influenced by the operating environment, power-on time, temperature, humidity, load, and maintenance conditions, and cannot be simply measured by a fixed number of years.

Design features: It uses industrial-grade hardware and is suitable for long-term continuous operation.

Actual life: The equipment with good maintenance and stable environment can run for a long time, but because the PLC-5 series has been discontinued, the actual life depends more on the aging degree of components and the supply of spare parts.

Key maintenance components: processor, power supply, backplane connector, communication interface and memory related components.

Measures to prolong the service life: keep the cabinet ventilated, dustproof, moisture-proof, and protected from high temperature and electrical shock. Check the power supply, communication, and fault status regularly.

FAQ

Q1. What should I do if the equipment fails to operate normally after power-on?

First check the PLC - 5 frame power supplies and back connection, and then observe the processor state indicator light; Further examination processor failure code, program state and communication links, using RSLogix 5 online diagnosis when necessary.

Q2. Can I purchase after production stop?

There may still be inventory, disassembly parts, refurbished parts, etc., in the market, but the product status varies greatly, so the procurement should focus on confirming the source and testing.

Q3. What items should be checked for DH+ communication abnormalities?

Focus on checking the DH+ cable, communication node address, terminal configuration, communication channel status and other node equipment. At the same time, confirm whether the processor communication status is normal.

Q4. Can other PLC-5 processors be used as substitutes?

You cannot judge by appearance alone. You need to confirm based on the PLC-5 system configuration, I/O quantity, communication method, program capacity and specific Series/Revision.

Q5. What should be checked when purchasing second-hand/refurbished products?

It is recommended to check the Allen Bradley 1785 L46B nameplate, Series, Revision, interface, appearance, power-on status, communication status and actual operation test results.
